Installation guide
Centering of washer on thread
Make sure the washer is not resting on one side of undercuts or radius of mating studs.
Material with low strength
A thicker and larger washer or an additional washer may be necessary when materials with low strength are used on the joint.
Large or slotted holes
An additional washer or a large washer is necessary to transfer the bolt load to a supported surface.
Space requirements
Check for space restrictions for socket and wrench combination.
Tensioner at the end of stud
An additional distance spacer may be necessary to bring tensioner closer to the end of the stud for proper socket fit.
Very long through-stud
A special tensioner with a larger circle of jackbolts may be necessary to properly access the jackbolts for tightening.
